Dual Silver Soft Coated Tempered LowE Glass

Dual Silver Soft Coated Tempered LowE Glass Dual Silver Soft Coated Tempered LowE Glass Dual Silver Soft Coated Tempered LowE Glass Dual Silver Soft Coated Tempered LowE Glass
Type Double Silver LowE Glass
Thickness 3,4,5,5.5,6,8,10,12mm
Other Colors Reflective Color: Silver Grey and Blue Grey
Standard Size 1650 x 2440, 1830 x 2440, 1650 x 2140, 2140 x 3300/3660, 2250 x 3300/3660, 2440 x 3300/3660
Jumbo Size




Incoterms EXW,FOB,CFR,CIF,CIP,DDU,DDP.
Lead time About 20 days upon receipt of your deposit or confirmation.
MOQ 100 Sqm.
Package Paper or powder interlayer between two glass panels and plywood crates with straps.
Payment Terms T/T, L/C, D/P, Western Union,Paypal.
Place of origin CHINA


Type Double Silver LowE Glass
Thickness 3,4,5,5.5,6,8,10,12mm
Other Colors Reflective Color: Silver Grey and Blue Grey
Standard Size 1650 x 2440, 1830 x 2440, 1650 x 2140, 2140 x 3300/3660, 2250 x 3300/3660, 2440 x 3300/3660
Jumbo Size




Incoterms EXW,FOB,CFR,CIF,CIP,DDU,DDP.
Lead time About 20 days upon receipt of your deposit or confirmation.
MOQ 100 Sqm.
Package Paper or powder interlayer between two glass panels and plywood crates with straps.
Payment Terms T/T, L/C, D/P, Western Union,Paypal.
Place of origin CHINA

DESCRIPTION

QDTE series is the high performance curved temperable double silver coating, is a solar control glass, which blocks up to 69% of solar heat by reflecting it to the outside. It can be for use in residential or commercial buildings alike, either for façades or overhead glazing. It will be another better option if you need SC within 0.25.

It has good levels of light transmittance, coupled with a low solar factor making it ideal for commercial projects which require high levels of solar heat rejection.

PRODUCT APPLICATION

  • Offices and commercial buildings
  • Industrial buildings
  • Hotels and restaurants
  • Schools and Hospitals

ADVANTAGE

  • More environmentally-friendly cooling solution with less need for costly air-conditioning or blinds.
  • Gently filters light to reduce uncomfortable glare from direct sun rays, whilst still allowing in plenty of natural light.
  • Excellent thermal insulation to reduce the need for internal heating during colder months.
Dual Silver Soft Coated Tempered LowE Glass Parameter
Configuration

Reflective

 Color

Visible Light Solar Energy U Value SC
Trans. Reflectance Trans. Ref. W/·K
Outside Inside Air Argon
6QDTE1140+12A+6C

  Silver

Grey

35 22 15 17 41 1.6 1.29 0.23
6QDTE1150+12A+6C

Blue

Grey

44 18 15 20 37 1.6 1.29 0.29
6QDTE1160+12A+6C

Blue

Grey

51 16 19 25 33 1.62 1.3 0.36
6QDTE1170+12A+6C

Blue

Grey

62 14 12 30 28 1.62 1.3 0.41
6QDTE1180+12A+6C Clear 69 12 11 32 32 1.64 1.31 0.45
Packing: Paper or powder interlayer between two glass panels and plywood crates or wooden crates with straps.

Crates type including  open crates, end cap, common frame as following:
