Sunergy Online Coated LowE Glass

Sunergy Online Coated LowE Glass Sunergy Online Coated LowE Glass Sunergy Online Coated LowE Glass Sunergy Online Coated LowE Glass
Type High Solar Shading
Thickness 5,6,8,10mm
Other Colors Clear, Dark Blue, Green, Grey, Azur
Standard Size 1650 x 2440, 1830 x 2440, 1650 x 2140, 2140 x 3300/3660, 2250 x 3300/3660, 2440 x 3300/3660
Jumbo Size 3300 x 5100mm
Incoterms EXW,FOB,CFR,CIF,CIP,DDU,DDP.
Lead time About 20 days upon receipt of your deposit or confirmation.
MOQ 100 Sqm.
Package Paper or powder interlayer between two glass panels and plywood crates with straps.
Payment Terms T/T, L/C, D/P, Western Union,Paypal.
Place of origin CHINA


Type High Solar Shading
Thickness 5,6,8,10mm
Other Colors Clear, Dark Blue, Green, Grey, Azur
Standard Size 1650 x 2440, 1830 x 2440, 1650 x 2140, 2140 x 3300/3660, 2250 x 3300/3660, 2440 x 3300/3660
Jumbo Size 3300 x 5100mm
Incoterms EXW,FOB,CFR,CIF,CIP,DDU,DDP.
Lead time About 20 days upon receipt of your deposit or confirmation.
MOQ 100 Sqm.
Package Paper or powder interlayer between two glass panels and plywood crates with straps.
Payment Terms T/T, L/C, D/P, Western Union,Paypal.
Place of origin CHINA

Sunergy

Solar Control Low-E Glass

Sunergy A is a pyrolytic, coated glass which has thin metal oxides by online CVD (Chemical Vapor Deposition) method, and it provides both of excellent properties; solar control and thermal insulation. Sunergy A has characteristics of low exterior reflection and color-neutral appearance, and it can be applied for high end architectural design and sophisticated aesthetics requirement.

In winter, Sunergy A prevents heat loss and keeps the indoor climate at an even temperature.

In summer, Sunergy A provides excellent solar shading and reduces heat gain into the building.

Products Features

  • Online hard coating
  • Stable, virtually unlimited shelf life, long life performance
  • Neutral color appearance, visual comfort, and low light reflection
  • High solar shading and thermal insulation
  • High durability, easy handling & easy processing (Cutting, laminating,tempering, bending, screen-printing)
  • Can be used as single glazing (surface position#2)
  • No edge deletion and no special handling for IGU

Products Applications

Sunergy A has low reflection, neutral appearance and several color variation. It can be used in advanced buildings and renovation projects as well. The optical properties can meet local regulations of low exterior reflection.

The combination of solar control and thermal insulation functions create ideal glass windows for a wide range of architectural applications; residential houses, office building, hospitals, schools, glass roofs and even more.



Sunergy Hard Coated LowE Glass Parameter
Structure Light Properties Thermal Properties U Value
     Single      Glazing Thickness LT% LR% EA% SF% SC      W/㎡ K      Air    W/㎡.K     Argon
   Sunergy    Clear 3mm 69 9 35 61 0.7 4.2
4mm 69 9 36 60 0.69 4.2
5mm 68 9 36 59 0.68 4.1
6mm 68 9 38 59 0.68 4.1
8mm 67 9 40 57 0.66 4.1
10mm 68 8 43 56 0.64 4.1
  Sunergy   Green 6mm 56 7 65 41 0.47 4.1
8mm 52 7 70 37 0.43 4.1
  Sunergy   Azur 4mm 60 8 54 48 0.55 4.1
6mm 56 7 61 43 0.49 4.1
8mm 52 7 67 40 0.46 4.1
10mm 48 7 70 37 0.43 4.1
Sunergy  Dark Blue 6mm 40 6 70 37 0.43 4.1
8mm 35 6 76 33 0.38 4.1
  Sungery    Grey 6mm 34 5 65 40 0.46 4.1
    Coating     in pos.2 Thickness LT% LR(Ext)% EA% SF% SC    W/㎡ K     Air   W/㎡.K    Argon
             Sunergy  Clear 4-9-4mm 62 13 41 53 0.61 2.4 2.1
4-12-4mm 62 13 41 52 0.6 2.2 1.9
5-9-5mm 61 12 43 52 0.6 2.4 2.1
5-12-5mm 61 12 43 51 0.59 2.2 1.9
6-12-6mm 61 12 44 50 0.57 2.2 1.9
6-15-6mm 61 12 44 50 0.57 2 1.8
8-12-8mm 59 12 48 49 0.56 2.1 1.9
8-15-8mm 59 12 48 48 0.55 2 1.8
10-12-10mm 58 12 51 47 0.54 2.1 1.9
10-15-10mm 58 12 51 47 0.54 2 1.8
    Sunergy     Green 6-12-6mm 50 10 68 32 0.37 2.2 1.9

Sunergy  Azur

 6-12-6mm 50 10 65 35 0.4 2.2 1.9
Sunergy  Dark Blue 6-12-6mm 36 8 72 29 0.33 2.2 1.9
Sunergy  Grey 6-12-6mm 30 6 70 32 0.37 2.2 1.9
1.The value and performance data shown in the tables are test results and not performance guarantees.
Packing: Paper or powder interlayer between two glass panels and plywood crates or wooden crates with straps.

Crates type including  open crates, end cap, common frame as following:
