| Type | Soft Coated Glass |
| Thickness | 3,3.2 4,5,5.5,6,8,10,12mm |
| Other Colors | Ford Blue,Dark Blue (Diamond Blue),Ocean Blue,Kunshan Blue,Crystal Blue French Green (Light Green),Dark Green(Natural Green) Euro Bronze(Grey Bronze),Golden Bronze, Pink Blue Grey,Dark Grey, Crystal Grey,Black Crystal Yellow. |
| Standard Size | 1650 x 2440, 1830 x 2440, 1650 x 2140, 2140 x 3300/3660, 2250 x 3300/3660, 2440 x 3300/3660 |
| Incoterms | EXW,FOB,CFR,CIF,CIP,DDU,DDP. |
| Lead time | About 10-15 days upon receipt of your deposit or confirmation. |
| MOQ | 100 Sqm. |
| Package | Paper or powder interlayer between two glass panels and plywood crates with straps. |
| Payment Terms | T/T, L/C, D/P, Western Union,Paypal. |
| Place of origin | CHINA |
| Type | Soft Coated Glass |
| Thickness | 3,3.2 4,5,5.5,6,8,10,12mm |
| Other Colors | Ford Blue,Dark Blue (Diamond Blue),Ocean Blue,Kunshan Blue,Crystal Blue French Green (Light Green),Dark Green(Natural Green) Euro Bronze(Grey Bronze),Golden Bronze, Pink Blue Grey,Dark Grey, Crystal Grey,Black Crystal Yellow. |
| Standard Size | 1650 x 2440, 1830 x 2440, 1650 x 2140, 2140 x 3300/3660, 2250 x 3300/3660, 2440 x 3300/3660 |
| Incoterms | EXW,FOB,CFR,CIF,CIP,DDU,DDP. |
| Lead time | About 10-15 days upon receipt of your deposit or confirmation. |
| MOQ | 100 Sqm. |
| Package | Paper or powder interlayer between two glass panels and plywood crates with straps. |
| Payment Terms | T/T, L/C, D/P, Western Union,Paypal. |
| Place of origin | CHINA |
Reflective glass
is an ordinary float glass with a metallic coating to reduce solar heat. This special metallic coating also produces a mirror effect, preventing the subject from seeing through the glass. It is mainly used in facades.usually reflective glass has hard coated glass and soft coated glass
Soft coated glass (coated off-line):in this process one or more coats of metal oxide are applied under a vacuum to finished glass. The coatings applied by this technique are soft and must be protected against external influences and are therefore used for the interior side of glass panes. There are some other techniques for the OFF-LINE coating:
Immersion Process
Chemical Process
Foil
Screened Glazin
Hard coated glass (coated On-Line): in this process, semi-conducted metal oxides are directly applied to the glass during the float glass production while the glass is still hot in the annealing lehr. These are hard coatings which are relatively harmful to the environment
Following is the reflective standard size and thickness:
| Thickness (mm) | Thickness Tolerance (mm) | Reflective Glass Panel Size mm | Max Loading Weight/CNT |
| 3, 3.2 | ±0.2 | 1650 x 2440, 1830 x 2440, 2000 x 2440, 2140 x 3050/3300/3660, 2250 x 3050/3300/3660, 2440 x 3050/3300/3660 | 27 Tons |
| 4 | ±0.2 | 1650 x 2440, 1830 x 2440, 2000 x 2440, 2140 x 3050/3300/3660, 2250 x 3050/3300/3660, 2440 x 3050/3300/3660 | 27 Tons |
| 5, 5.5 | ±0.2 | 1650 x 2440, 1830 x 2440, 2000 x 2440, 2140 x 3050/3300/3660, 2250 x 3050/3300/3660, 2440 x 3050/3300/3660 | 27 Tons |
| 6 | ±0.2 | 1650 x 2440, 1830 x 2440, 2000 x 2440, 2140 x 3050/3300/3660, 2250 x 3050/3300/3660, 2440 x 3050/3300/3660 | 27 Tons |
| 8 | ±0.3 | 1650 x 2440, 1830 x 2440, 2000 x 2440, 2140 x 3050/3300/3660, 2250 x 3050/3300/3660, 2440 x 3050/3300/3660 | 27 Tons |
| 10 | ±0.3 | 1650 x 2440, 1830 x 2440, 2000 x 2440, 2140 x 3050/3300/3660, 2250 x 3050/3300/3660, 2440 x 3050/3300/3660 | 27 Tons |
| 12 | ±0.3 | 1650 x 2440, 1830 x 2440, 2000 x 2440, 2140 x 3050/3300/3660, 2250 x 3050/3300/3660, 2440 x 3050/3300/3660 |
27 Tons |
Soft coated glass (coated off-line) VT can reach 10%
.JPG)
.jpg)
Kindly processed glasses Products are fully accredited to enable you to buy with confidence. Our accreditation include:
ISO9001 | China GB | EN(European Norm) | ANSI(American National Standards Institute) | AS/NZS
Kindly Glass & Mirror is a professional supplier of glass panels and good manufacturer of processed glass panels.
