Tempered, Toughened Safety Glass

Tempered, Toughened Safety Glass Tempered, Toughened Safety Glass Tempered, Toughened Safety Glass Tempered, Toughened Safety Glass
Type Building Tempered Glass
Thickness 3,4,5,5.5,6,8,10,12,15,19,22,25mm
Other Colors French Green (Light Green),Dark Green(Natural Green); Ford Blue, Dark Blue (Diamond Blue); Ocean Blue, Kunshan Blue, Crystal Blue; Euro Bronze(Grey Bronze), Golden Bronze, Pink; Blue Grey,Dark Grey, Crystal Grey, Black; Crystal Yellow.
Standard Size Flat shape: circular / triangle / square / rectangular / diamond / cylindrical / Pentagon / ladder / parallelogram / hexagon heptagon octagon / eight / nine / ten edge edge / irregular graphics / oval.
Jumbo Size 3000x15000mm
Incoterms EXW,FOB,CFR,CIF,CIP,DDU,DDP.
Lead time About 20 days upon receipt of your deposit or confirmation.
MOQ 100 Sqm.
Package Paper or powder interlayer between two glass panels and plywood crates with straps.
Payment Terms T/T, L/C, D/P, Western Union,Paypal.
Place of origin CHINA


Type Building Tempered Glass
Thickness 3,4,5,5.5,6,8,10,12,15,19,22,25mm
Other Colors French Green (Light Green),Dark Green(Natural Green); Ford Blue, Dark Blue (Diamond Blue); Ocean Blue, Kunshan Blue, Crystal Blue; Euro Bronze(Grey Bronze), Golden Bronze, Pink; Blue Grey,Dark Grey, Crystal Grey, Black; Crystal Yellow.
Standard Size Flat shape: circular / triangle / square / rectangular / diamond / cylindrical / Pentagon / ladder / parallelogram / hexagon heptagon octagon / eight / nine / ten edge edge / irregular graphics / oval.
Jumbo Size 3000x15000mm
Incoterms EXW,FOB,CFR,CIF,CIP,DDU,DDP.
Lead time About 20 days upon receipt of your deposit or confirmation.
MOQ 100 Sqm.
Package Paper or powder interlayer between two glass panels and plywood crates with straps.
Payment Terms T/T, L/C, D/P, Western Union,Paypal.
Place of origin CHINA

Tempered glass / Toughened glass

is two or more times stronger than annealed glass. When broken, it shatters into many small fragments which prevent major injuries. This type of glass is intended for glass facades, sliding doors, building entrances, bath and shower enclosures and other uses requiring superior strength and safety properties.

Production

There are two different methods used to produce tempered glass.

*Heat treating

Where the annealed glass is subjected to a special heat-treatment in which it is heated to about 680°C and afterwards cooled. If it is cooled rapidly, the glass is up to four times stronger then annealed glass and its breaks into many small fragments (fully-tempered). If it is cooled slowly, the glass is twice as strong as annealed glass and the fragments of the broken glass are linear and more likely to remain in the frame.

*Chemical strengthening

The glass is covered by a chemical solution which produces a higher mechanical resistance. Chemically-strengthened glass has similar properties to thermal-treated glass. The product is not generally used for window glass, but more commonly seen in industries where thin, strong glass is needed.

Tempered / Toughened Safety Glass Processed Specification

1.3D shape: C standard curved, multi-radius curved,moulded processed and J curved.

2. Flat shape: circular / triangle / square / rectangular / diamond / cylindrical / Pentagon / ladder / parallelogram / hexagon heptagon octagon / eight / nine / ten edge edge / irregular graphics / oval.

3. Edge work:flat, pencil, bevel, ogee, waterfall ,convex edge.

4. Surface:acid etched, ink printing, coated, lacquered, painted, mechanical grooving,preventing water spots, laser engraved,etc.

5. Corner work:fillet, chamfer,etc.

6. Cutout work:hole, notch, shape cutout,etc.

7. Glass color:clear, ultra clear, bronze, green, pink, grey, blue,etc.

8. J curved data: 450 x ⌒450mm to 2000x ⌒900mm fit for 5-8mm glass.   Rmin:450mm, Rmax:10000mm.

Kindly Tempered Glass Specification

Thickness

Available Color

Flat Tempered

Curved Tempered

Other Curved Solution

Edge Work

Corner &  Processing

Subsequent Process

Min.Size

Max.Size

Min.Size

Max.Size

Min.Radius

2

Clear

10 x 10mm

1000 x 1000mm

/

/

/

Hot Bending

Flat ,Pencil

Fillets,Chamfers,Cutouts,Notches, Holes,Engrave

Laminated , Silk-Screen,  Lacquered

3-3.7

Clear,LowE,Bronze,Blue,Green

10 x 10mm

1000 x 2000mm

/

/

/

Hot Bending

Flat ,Pencil

Laminated, Insulated, Silk-Screen,  Lacquered

4,5,6,8,10,12

Clear,LowE,Bronze,Blue,Green,Grey,Pink tinted and reflective glass, Patterned Glass(4,5,6,8mm)

10 x 10mm

(2430-3290)x (3660- 6500)mm

500 x 500mm

2440 x 4800mm

450mm / Double,Multi-Curved

Hot Bending

Flat,Pencil,  Bevel,Ogee,Waterfall, Convex

Laminated, Insulated, Silk-Screen,  Lacquered

15,19

Clear, Soft LowE

25 x 25mm

3290 x 15000mm

500 x 500mm

2440 x 4800mm

1500mm / Double,Multi-Curved

Hot Bending

Flat,Pencil,  Bevel,Ogee,Waterfall, Convex

Laminated, Insulated, Silk-Screen,  Lacquered

22,25

Clear

50 x 50mm

3290 x 15000mm

500 x 500mm

2440 x 4800mm

1500mm / Double,Multi-Curved

Hot Bending

Flat,Pencil,  Bevel,Ogee,Waterfall, Convex

Laminated, Insulated, Silk-Screen,  Lacquered

Kindly Products Protection Packing

Interlayer Protection

Corner Packing

Edge Packing

Inner Packing

Outer Packing

LCL Packing

Anti-Fungicide Paper

Right Angle Plastic Corner

EPS Side Fender

Paper Wrap

Plywood Crate

Case Min.Width > 650mm   Max.Length <1500mm    Max. Height < 1200mm

Anti-Fungicide Powder

Plump Plastic Corner



Single-layer Paperboard

Plywood Case

Case + L Rack with Four-sided Forklift

EPE Film

Paperboard Corner



Double-layer Paperboard

Plywood Pallet Crate

A-type Case

Cork Mat

EPS Corner



Carton

Nude Packing + A Rack

Pallet Case

EPS Board





PVC,EPE Shrink Film





Related Products

Kindly processed glasses Products are fully accredited to enable you to buy with confidence. Our accreditation include:

ISO9001    |    China GB    |    EN(European Norm)    |    ANSI(American National Standards Institute)    |    AS/NZS
