| Thickness | 3,4,5,5.5,6,8 mm |
| Standard Size | 1650 x 2440, 1830 x 2440, 1650 x 2140, 2140 x 3300/3660, 2250 x 3300/3660, 2440 x 3300/3660 |
| Incoterms | EXW,FOB,CFR,CIF,CIP,DDU,DDP. |
| Lead time | About 20 days upon receipt of your deposit or confirmation. |
| MOQ | 100 Sqm. |
| Package | Paper or powder interlayer between two glass panels and plywood crates with straps. |
| Payment Terms | T/T, L/C, D/P, Western Union,Paypal. |
| Place of origin | CHINA |
| Thickness | 3,4,5,5.5,6,8 mm |
| Standard Size | 1650 x 2440, 1830 x 2440, 1650 x 2140, 2140 x 3300/3660, 2250 x 3300/3660, 2440 x 3300/3660 |
| Incoterms | EXW,FOB,CFR,CIF,CIP,DDU,DDP. |
| Lead time | About 20 days upon receipt of your deposit or confirmation. |
| MOQ | 100 Sqm. |
| Package | Paper or powder interlayer between two glass panels and plywood crates with straps. |
| Payment Terms | T/T, L/C, D/P, Western Union,Paypal. |
| Place of origin | CHINA |
Silver mirror：
High quality float glass or polished glass substrate is coated with a layer of reflective silver.A layer of copper,
Which is in turn protected by a painted backing, usually protects this deposit. The silver give the mirror its reflective
Properties.
Thickness：
2,3,4,5,6,8mm
Tolerance：2-6:+/-0.2mm,8:+/-0.3mm
Size as below:
| Thickness(mm) | Silver Mirror Panel Size(mm) | Max Loading Weight/CNT |
| 2 | 1220*1830 1500x2000 1650x2200 1830x2440 | 27 Tons |
| 3 |
1220*1830 1500x2000 1650x2200 1830x2440 2134/2140x3300/3660 2440x3300/3660 |
27 Tons |
| 4 |
1220*1830 1500x2000 1650x2200 1830x2440 2134/2140x3300/3660 2440x3300/3660 |
27 Tons |
| 5 |
1220*1830 1500x2000 1650x2200 1830x2440 2134/2140x3300/3660 2440x3300/3660 |
27 Tons |
| 6 |
1220*1830 1500x2000 1650x2200 1830x2440 2134/2140x3300/3660 2440x3300/3660 |
27 Tons |
| 8 |
1220*1830 1500x2000 1650x2200 1830x2440 2134/2140x3300/3660 2440x3300/3660 |
27 Tons |
| Silver Mirror Parameter | ||||
| Thickness | Ref. Ratio % | Thickness | ||
| Silver Layer | Copper Layer | Double Paint | ||
| 3mm | 93.94 | ≥750mg/㎡ | ≥200mg/㎡ | 45-60μm |
| 4mm | 91.83 | |||
| 5mm | 91.17 | |||
| 6mm | 90.14 | |||
| Copper Free Silver Mirror Parameter | ||||
| Thickness | Ref. Ratio % | Thickness | ||
| Silver Layer | Double Paint | Lead Content | ||
| 3mm | 94.27 | ≥900mg/㎡ | 45-60μm | 0-5PPM |
| 4mm | 92.04 | |||
| 5mm | 91.35 | |||
| 6mm |
90.33 |
|||
Packing: Paper or powder interlayer between two glass panels and plywood crates or wooden crates with straps.
Crates type include open crates, end cap, common frame.
Kindly processed glasses Products are fully accredited to enable you to buy with confidence. Our accreditation include:
ISO9001 | China GB | EN(European Norm) | ANSI(American National Standards Institute) | AS/NZS
Kindly Glass & Mirror is a professional supplier of glass panels and good manufacturer of processed glass panels.
