| Type | Automotive Glass |
| Thickness | 1.6 mm -6 mm |
| Standard Size | Max size : 6500* 3300 mm Min size : 500* 700 mm Size can be customized. |
| Incoterms | EXW,FOB,CFR,CIF,CIP,DDU,DDP. |
| Lead time | About 10-15 days upon receipt of your deposit or confirmation. |
| MOQ | 100 Sqm. |
| Package | Paper or powder interlayer between two glass panels and plywood crates with straps. |
| Payment Terms | T/T, L/C, D/P, Western Union,Paypal. |
| Place of origin | CHINA |
| Type | Automotive Glass |
| Thickness | 1.6 mm -6 mm |
| Standard Size | Max size : 6500* 3300 mm Min size : 500* 700 mm Size can be customized. |
| Incoterms | EXW,FOB,CFR,CIF,CIP,DDU,DDP. |
| Lead time | About 10-15 days upon receipt of your deposit or confirmation. |
| MOQ | 100 Sqm. |
| Package | Paper or powder interlayer between two glass panels and plywood crates with straps. |
| Payment Terms | T/T, L/C, D/P, Western Union,Paypal. |
| Place of origin | CHINA |
Recommended SOLAR GREEN (A-GREEN) TINTED FLOAT GLASS FOR AUTOMOBILE
Solar Green (A-Green) tinted float glass has high absorbability of ultraviolet radiation and infrared. It was developed by Pilkington Groups R&D Dept..
With special colourant added in the production of normal float glass , Solar Green (A-Green) has much better ultraviolet and infrared absorbing performance than ordinary body – tinted glass . It is a kind f high absorbing , high transmittance, fashionable color appearance, energy-saving tinted float glass.
Pilkington’s Solar Green (A – Green) tinted float glass can meet different requirements for visual effects and energy saving effects of automotive and architectural industry. You can also do further processing by tempering , insulating and laminating.
In terms of automotive industry , with the strong advantage of tinted float glass ,SYP Group is now the most important supplier of automotive glass manufactures. We are so confident that Solar Green (A-Green) will become the next generation of popular products in the automotive glass industry.
FEATURES
APPLICATIONS
SOLAR GREEN (A-GREEN) TINTED FLOAT GLASS FOR AUTOMOBILE
|
Product |
Thickness (mm) |
Optic Character (%)&test Specification |
Color haracter & test specification |
|||||
|
LTA (light transmittance) |
TE (Solar direct transmittance) |
TUV (UV-Transmittance) |
TIR Near –Infrared (transmittance) |
L* |
a* |
a* |
||
|
380 nm-780nm |
300 nm – 2500 nm |
300nm – 380 nm |
780 – 2500 nm |
1931CIE L*a*b* D65 Standard illuminants Field of view 2. |
||||
|
ISO9050 -2003 |
||||||||
(Solar green) |
1.6+0.1 |
83.5 |
67.1 |
43.3 |
53.7 |
93.6 |
-3.5 |
0.6 |
|
2.1+0.1 |
81.5 |
62.2 |
38.5 |
46.6 |
92.8 |
-4.5 |
0.8 |
|
|
2.3+0.1 |
80.6 |
60.3 |
36.2 |
44.0 |
92.4 |
-4.8 |
0.9 |
|
|
3.2+0.1 |
76.7 |
52.6 |
29.5 |
33.3 |
90.8 |
-6.6 |
1.1 |
|
|
3.5+0.1 |
75.2 |
50.0 |
27.3 |
39.9 |
90.2 |
-7.3 |
1.1 |
|
|
3.85+0.1 |
73.4 |
47.3 |
24.8 |
26.7 |
89.4 |
-8.0 |
1.3 |
|
|
4.0+0.1 |
73.1 |
46.4 |
24.0 |
25.0 |
89.4 |
-8.1 |
1.3 |
|
|
5.0+0.1 |
71.5 |
44.0 |
22.0 |
22.0 |
88.5 |
-9.0 |
1.3 |
|
|
Tolerance |
|
+2.0 |
+3.0 |
+3.0 |
+3.0 |
|
||
Packing:
| Interlayer Protection | Corner Packing | Edge Packing | Inner Packing | Outer Packing | LCL Packing |
| Anti-Fngicide Paper | Right Angle Plastic Corner | EPS Side Fender | Paper Wrap | Plywood Crate | Case Min.Width > 650mm Max.Length <1500mm Max. Height < 1200mm |
| Anti-Fngicide Powder | Plump Plastic Corner | Single-layer Paperboard | Plywood Case | Case + L Rack with Four-sided Forklift | |
| EPE Film | Paperboard Corner | Double-layer Paperboard | Plywood Pallet Crate | A-type Case | |
| Cork Mat | EPS Corner | Carton | Nude Packing + A Rack | Pallet Case | |
| EPS Board | PVC,EPE Shrink Film |
Kindly processed glasses Products are fully accredited to enable you to buy with confidence. Our accreditation include:
ISO9001 | China GB | EN(European Norm) | ANSI(American National Standards Institute) | AS/NZS
Kindly Glass & Mirror is a professional supplier of glass panels and good manufacturer of processed glass panels.
Eab*≤ 2.5
