PVE Laminated Glass

PVE Laminated Glass PVE Laminated Glass PVE Laminated Glass PVE Laminated Glass
Type PVE Laminated Glass
Thickness 2mm + 0.38mmPVE + 2mm
3mm + 0.38mmPVE + 3mm
4mm + 0.38mmPVE + 4mm
.......
12mm + 2.28mmPVE + 12mm
Other Colors Clear
Standard Size 2440*3660mm and Customized Dimension.
Incoterms EXW,FOB,CFR,CIF,CIP,DDU,DDP.
Lead time About 20 days upon receipt of your deposit or confirmation.
MOQ 100 Sqm.
Package Paper or powder interlayer between two glass panels and plywood crates with straps.
Payment Terms T/T, L/C, D/P, Western Union,Paypal.
Place of origin CHINA


Type PVE Laminated Glass
Thickness 2mm + 0.38mmPVE + 2mm
3mm + 0.38mmPVE + 3mm
4mm + 0.38mmPVE + 4mm
.......
12mm + 2.28mmPVE + 12mm
Other Colors Clear
Standard Size 2440*3660mm and Customized Dimension.
Incoterms EXW,FOB,CFR,CIF,CIP,DDU,DDP.
Lead time About 20 days upon receipt of your deposit or confirmation.
MOQ 100 Sqm.
Package Paper or powder interlayer between two glass panels and plywood crates with straps.
Payment Terms T/T, L/C, D/P, Western Union,Paypal.
Place of origin CHINA

High strength PVE(Polyvinyl Ether) interlayer for architecture laminated glass especially suitable for laminated glass application places where weather resistance, high temperature- humidity, low temperature and other harsh environments require high safety performance, such as outdoor building roof and curtain wall, decorative curtain wall, glass handrail, sunshine room and so on.

Characteristics
1.High permeability, low haze, high strength .
2.Crosslinked film, strong adhesive at high-low temperature.
3.Edge water resistance and stable， anti-combustion drip.
4.Suitable for nip roll+ autoclave process.
5.Low water absorption, room temperature storage & transportation.

Performance

Test Method

PVE-G301

Physical Performance

Thickness

Thickness Gauge

0.38mm，0.76mm

Crosslinking Degree

T/CPIA 0004-2017

≥85%

180°
Peel Strength

GB/T 2790

≥50N/cm

Tensile Strength

GB/T 1040.3-2006

≥20MPa

Optical Performance

Light Transmittance

GB/T 2680

≥86%

Haze

GB/T 2410-2008

≤0.7%

UV Transmittance

GB/T 2680

≤5%

Weather Ability

Boiling Test

GB 15763.3-2009

No bubble, delamination or white mist defects within 10mm of the  edge or crack

Damp Heating Test

GB 15763.3-2009

No bubble, delamination or white mist defects within 10mm of the  edge or crack
Visible light transmission ratio    change Rate ≤5%

Irradiation Resistance

GB/T 5137.3-2002

Visible light transmission ratio    change Rate ≤3%
No bubble, delamination or white mist defects
