Type | PVB Laminated Glass |
Thickness | 4.38, 5.38, 6.38, 8.38, 10.38, 10.76 mm 22.1, 33.1, 44.1,55.2,66.2,88.2,1010.2 mm 1010.2 , 1515.2, 1919.2 mm 1010.4 , 1515.6, 1919.6 mm |
Other Colors | French Green (Light Green),Dark Green(Natural Green); Ford Blue, Dark Blue (Diamond Blue); Kunshan Blue, Crystal Blue; Ocean Blue, Euro Bronze(Grey Bronze), Golden Bronze, Blue Grey,Dark Grey, Crystal Grey, Black; Crystal Yellow.Pink |
Standard Size | 610*914,914*1220,1830*1220,1524*2134,1650*2140,914*2440,1070*2440, 1220*2440,1650*2440,1830*2140,1830*2440,1830*3050,1830*3210, 1830*3300,1830*3660,2140*3050,2140*3210,2140*3300,2140*3660,2250*3050, 2250*3210,2250*3300,2250*3660,2440*3050,2440*3210,2440*3300,2440*3660 2550*1650,2550*2440,2550*3050,2550*3210,2550*3300,2550*3660 |
Jumbo Size | 3300*13000 mm 3300*14000 mm 3300*15000 mm |
Incoterms | EXW,FOB,CFR,CIF,CIP,DDU,DDP. |
Lead time | About 20 days upon receipt of your deposit or confirmation. |
MOQ | 100 Sqm. |
Package | Paper or cord pad interlayer between two glass panels and plywood crates with straps. |
Payment Terms | T/T, L/C, D/P, Western Union,Paypal. |
Place of origin | CHINA |
Type | PVB Laminated Glass |
Thickness | 4.38, 5.38, 6.38, 8.38, 10.38, 10.76 mm 22.1, 33.1, 44.1,55.2,66.2,88.2,1010.2 mm 1010.2 , 1515.2, 1919.2 mm 1010.4 , 1515.6, 1919.6 mm |
Other Colors | French Green (Light Green),Dark Green(Natural Green); Ford Blue, Dark Blue (Diamond Blue); Kunshan Blue, Crystal Blue; Ocean Blue, Euro Bronze(Grey Bronze), Golden Bronze, Blue Grey,Dark Grey, Crystal Grey, Black; Crystal Yellow.Pink |
Standard Size | 610*914,914*1220,1830*1220,1524*2134,1650*2140,914*2440,1070*2440, 1220*2440,1650*2440,1830*2140,1830*2440,1830*3050,1830*3210, 1830*3300,1830*3660,2140*3050,2140*3210,2140*3300,2140*3660,2250*3050, 2250*3210,2250*3300,2250*3660,2440*3050,2440*3210,2440*3300,2440*3660 2550*1650,2550*2440,2550*3050,2550*3210,2550*3300,2550*3660 |
Jumbo Size | 3300*13000 mm 3300*14000 mm 3300*15000 mm |
Incoterms | EXW,FOB,CFR,CIF,CIP,DDU,DDP. |
Lead time | About 20 days upon receipt of your deposit or confirmation. |
MOQ | 100 Sqm. |
Package | Paper or cord pad interlayer between two glass panels and plywood crates with straps. |
Payment Terms | T/T, L/C, D/P, Western Union,Paypal. |
Place of origin | CHINA |
Laminated glass is a combination of two or more glass sheets with one or more interlayers of plastic (PVB) or resin. In case of breakage, the interlayer holds the fragments together and continues to provide resistance to the passage of persons or objects. This glass is particularly suitable where it is important to ensure the resistance of the whole sheet after breakage such as: shop-fronts, balconies, stair-railings, roof glazing.
Production:
There are two types of laminated glass: PVB and resin laminated glass: PVB laminated glass is two or more sheets of glass which are bonded together with one or more layers (PVB) under heat and pressure to form a single piece. Resins laminated glass is manufactured by pouring liquid resin into the cavity between two sheets of glass which are held together until the resin cures.
Features:
1) Extremely high safety: The PVB interlayer withstands penetration from impact. Even if the glass cracks, splinters will adhere to the interlayer and not scatter. In comparison with other kinds of glass, laminated glass has much higher strength to resist shock, burglary, burst and bullets.
2) Energy-saving building materials: PVB interlayer impedes the transmission of solar heat and reduces cooling loads.
3) Create aesthetic sense to buildings: Laminated glass with a tinted interlayer will beautify the buildings and harmonize their appearances with surrounding views which meet the demand of architects.
4) Sound control: PVB interlayer is an effective absorber of sound.
5) Ultraviolet screening: The interlayer filters out ultraviolet rays and prevents the furniture and curtains from fading effec
Thickness |
6.38mm, 8.38mm, 10.38mm, 12.38mm, 42.3mm etc. Double layers, Triple layers, Fourth layers... |
Size | 1830*2440mm, 3300*2134mm, 3300*2140mm etc. |
PVB Color | Clear, Milk, F. Green, Bronze, Light Grey, Dark Grey, Ocean Blue etc. |
Glass Color |
Clear, Dark Bronze, Light Bronze, Dark Grey, Euro Grey, Mist Grey, Dark Green, F. Green, Dark Blue, Lake Blue etc. |
Customer | Exporting to more than 50 countries in the world. |
Certificate | CE, ISO9001, AS/NZS2208:1996, SGS, EN12150 |
Experience |
more than 10 years experience on glass manufacturing and exporting. |
Packing |
Safety sea-worthy wooden or plywood packing. |
Packing: Paper or cord pad interlayer between two glass panels and plywood crates with straps.
Kindly processed glasses Products are fully accredited to enable you to buy with confidence. Our accreditation include:
ISO9001 | China GB | EN(European Norm) | ANSI(American National Standards Institute) | AS/NZS
Kindly Glass & Mirror is a professional supplier of glass panels and good manufacturer of processed glass panels.
